Cubed

Cubed is a real-time voxel rendering engine written from scratch in C and Vulkan. It uses hardware raytracing to render each scene, with a compute-shader backed fallback when it is not supported. It supports real-time dynamic illumination via a novel algorithm I dubbed Hierarchical Voxel Irradiance Caching. I write it up as I go in a series of video devlogs.

Highlights

• Raytracing pipeline on Vulkan hardware RT, with a compute-shader software fallback and a wide BVH accelerator.
• Several voxel data structures: 64-trees, brickmaps, and flat volumes, each with a custom intersection shader. Profiling in Nsight surfaced cache misses; reworking the memory layout cut frame times ~20%.
• Indirect dispatch builds a world-space octree forest under a fixed memory budget, backed by a custom Vulkan allocator. It drives infinite-bounce GI with screen-space-constant probe sizing.
• A cascaded shadow map with PCF drives both primary shadows as well as direct light queries for GI rays.
